Briggs & Stratton 5.0hp (725EXi Series) Lawnmower Engine

Price range: $442.00 through $479.00

Check Delivery Cost

Enter your postcode to check delivery options before checkout.

Did you like this product? Add to favorites now and follow the product.

Add to wishlist
Need product advice?

Call Hampton Mower Centre on (03) 9598 6741

Low Prices

Price match guarantee

Expert Product Advice.

Contact Hampton Mower Centre for fitment and parts support.

In-House Experts.

We know our products

Easy Returns.

Quick & Hassle Free

Categories: ,
Tag:

Description

Description

DESCRIPTION

Briggs & Stratton EXi Series Engines, the first walk-behind mower engine featuring Just Check and Add? so you’ll never need an oil change-ever. Redesigned from the ground up, EXi Series Engines are lightweight and easy to maneuver, have tool-less access for easy maintenance, and come equipped with the ReadyStart? Starting System with no prime, no choke-just pull for power. Powerful, durable, easy to use and easy to maintain.

KEY FEATURES

  • Just Check and Add – Industry First – No Oil Changes
  • Ready start Starting System
  • Magnetron Electronic Ignition
  • Duralube Splash Lubrication System
  • Dual Sealing paper element w/ Tool Less Access
  • Over Head Valve Engine (OHV)
  • Lightweight design – Lightest engine in its class
  • 1 Litre Fuel Tank included w/ angled Fuel neck
  • Aluminized Super Lo-tone engine muffler
  • Electronic Ignition
  • Multiple Shaft Options for different mowers
  • 2 Year Consumer Warranty
  • 335 (mm) x 213 (mm) x 256 (mm) (LxWxH)
  • 2 Year Warranty – Australia Wide

    SPECIFICATIONS

    Engine Series

    Briggs & Stratton EXi?Series

    Engine Style

    Vertical

    Cylinders

    1

    Engine Type

    4 Cycle OHV

    Cooling System

    Air

    Dry Weight

    18.8?Lbs

    Engine CC

    163cc

    Engine HP

    5hp

    Cylinder Bore Type

    Aluminium

    Bore

    2.69?inches

    Stroke

    1.75?inches

    Starting System

    Recoil Start

    Ignition System

    Electronic Spark

    Oil Filter

    No

    Oil capacity

    15?oz

    Muffler

    Included

    Air Cleaner

    Dry (paper)

    Fuel Tank

    1 Litre

    Crankshaft Rotation

    Counterclockwise

    Shaft Sizes

    Options listed above

    Crankshaft Type

    Straight Keyway

    Crankshaft Diameter

    7/8 inch or 25ml

    Crankshaft Length

    70ml?or 50ml

    Crankshaft End Tapped Size

    3/8-24

    Crankshaft Keyway Width

    3/16?Inches

    Warranty

    2 Years

    Dimensions

    ?

    Need workshop support or a repair?

    For repairs and servicing, Hampton Mowerpower is the physical workshop at 87 Ludstone Street, Hampton VIC 3188. Commercial equipment repairs are normally targeted at approximately 1-2 business days and domestic repairs approximately 3-4 business days, subject to diagnosis, approval, parts availability, repair complexity and workshop conditions.

    Request a repair | View repair services | Call (03) 9598 6741

    Not sure if the machine is worth repairing or whether an engine can be replaced? Ask first with the equipment type, brand/model and symptoms.

    Need a repair before replacing the machine?

    Commercial Repair Priority — Typical Turnaround 1–2 Business Days. Domestic Repairs — Typical Turnaround 3–4 Business Days. Typical turnaround applies once the machine has been assessed and the repair is approved. Special-order or backordered parts, major engine work, unusual faults or additional diagnosis may take longer.

    Repair labour: Lawn Mower $89 + parts; Chainsaw $89 + parts; Line Trimmer / Brushcutter $89 + parts. Minor repairs $22 / $44 / $55 + parts depending on the work required. Larger / commercial equipment including Demo Saw, Jackhammer, Generator, Ride-On Mower, Wacker / Compaction Equipment and Shredder: $155 + parts.

    3-Month Domestic Repair & Service Warranty. This warranty relates to the domestic repair/service work performed.

    Book a repair | View repair pricing | Call (03) 9598 6741 | Get directions

    Additional information

    Weight15 kg
    Dimensions70 × 50 × 45 cm
